Product Introduction: In semi-programmed full-flow ozone disinfection systems, HQ-OZ reaction tanks must be configured to remove excess ozone through activated carbon adsorption while simultaneously eliminating odors, tastes, and organic matter...
Product Introduction:In semi-programmed full-flow ozone disinfection systems, HQ-OZ reaction tanks must be configured to remove excess ozone through activated carbon adsorption while simultaneously eliminating odors, tastes, and organic matter from the water. This process reduces harmful water treatment byproducts such as chloroform and chloroacetic acid, and further decreases pool water turbidity. Backwashing is manually controlled based on the inlet/outlet pressure differential and operational time.
Technical Features:
Reaction Standard: Designed to meet the reaction formula CT ≥ 1.6.
Ozone Demand Calculation:PO3=qc×O3.
Tank Sizing Calculation:V=(qc/60)×t.
Variable Definitions:
C: Ozone dosage added to the water.
t: Required contact/reaction time between ozone and water.
V: Volume of the reaction tank.
qc: Circulation flow rate of the swimming pool.
Product Advantages:
The tank body features a UV-resistant protective layer and is reinforced with fiberglass winding.
The interior of the tank is equipped with an anti-corrosion coating.
Thorough reaction between water and ozone significantly enhances the sterilization effect.
